5.0 Inch HMI TFT LCD Model:DMG80480T050_09W(Industrial grade)
Features:
● Based on T5L0 ASIC 5.0 Inch,800xRGBx480,262K Colors, IPS screen;
● High brightness;
● No Touch/Resistive touch/Capacitive display modules optional;
● TTL/RS232 interface; 8Pin_2.0mm connection wire;
● Download files via SD card or on-line serial port;
● Easy-to-use DWIN DGUS V7.6 GUIs Development,no coding skills required;
● Dual Development System: DGUSⅡ/TA(Instruction set);
● IPS View Angle:85/85/85/85(L/R/U/D);
● With GUI&OS dual-core, GUI with rich controls, DWIN OS kernel is open to the user for the second-development, via DWIN OS language or KELI C51.
-
4.3 Inch Smart LCD Model: DMG80480C043_02W(Commercial Grade)
Features
● Based on self-designed T5L1 ASIC, 16.7M Color, 24bit, 480*800 Pixel TFT LCD;
● No touch screen/Resistive touch screen/Capacitive touch screen Optional;
● TTL Interface,10Pin1.0mm FCC connection wire;
● Download via SD card or on-line serial port;
● Easy-to-use DWIN DGUS V7.6 GUIs Development, no coding skills required;
● Dual Development System: DGUS II/ TA(Instruction set);
● IPS View Angle: 85/85/85/85 (L/R/U/D) ;
-
4.3 Inch Touch Display Model: DMG48270C043_05W(Commercial Grade)
Features:
● Based on T5L0, running DGUS II system, commercial grade.
● 4.3-inch, 480*272 Pixels resolution, 262K Colors, TN-TFT-LCD, normal viewing angle.
● No touch /Resistive touch /Capacitive touch screen optional;
● 8MB memory, cost-effective.
● 10Pin1.0mm FCC connection wire,RS 232 Interface;
● HMI intelligent display for commercial grade application
● With GUI & OS dual-core, GUI with rich controls.
-
5 Inch HMI TFT LCD Module With Shell DMG80480T050_A5W (Industrial Grade)
Features:
● 800*480 pixels resolution, 16.7M Colors, IPS-TFT-LCD, wide viewing angle;
● Industrial Grade TFT LCD panel, IP65 protective level;
● With shell, with conformal coating. Resistive/Capacitance touch screen;
● RS232/RS485 Interface,8Pin3.81mm Socket;
● Support point touch and drag;
● IPS View Angle: 85/85/85/85 (L/R/U/D) ;
-
9.7 Inch HMI TFT LCD Display Model: DMG10768C097_03W(Commercial grade)
Features:
●Based on T5L ASIC 9.7 Inches, 1024xRGBx768, 16.7M Colors, Cost-Effective screen;
●No /Resistive /Capacitive touch screen Optional;
●UART2: ON=TTL/CMOS; OFF=RS232; 8Pin_2.0mm FCC Socket;
●Download via SD card or on-line serial port;
●Easy-to-use DWIN DGUS V7.6 GUIs Development.no coding skills required;
●Dual Development System:DGUSⅡ/TA(Instruction set);
●TN View Angle: 70°/70°/50°/70° (L/R/U/D);
●With GUI & OS dual-core, GUI with rich controls. DWIN OS kernel is open to the user for the second-development, via DWIN OS language or KEIL C51. -
8 Inch HMI LCD Module Model: DMG12800C080_03W(Commercial grade)
Features：
● Based on T5L ASIC 8.0 Inches, 1280xRGBx800, 16.7M Colors, IPS screen, Cost-Effective screen;
● No /Resistive /Capacitive touch screen Optional;
● UART2: ON=TTL/CMOS; OFF=RS232 UART4: ON=TTL/CMOS; OFF=RS232; 8PIN_2.0mm Socket;
● Download via SD card or on-line serial port;
● Easy-to-use DWIN DGUS V7.6 GUIs Development.no coding skills required;
● Dual Development System:DGUSⅡ/TA(Instruction set);
● IPS View Angle:85/85/85/85(L/R/U/D);
● With GUI & OS dual-core, GUI with rich controls. DWIN OS kernel is open to the user for the second-development, via DWIN OS language or KEIL C51.
-
7 inch HMI TFT LCD Touch DMG80480C070_06W(Commercial grade)
Features:
● Based on T5L ASIC 7.0 inches, 800*RGB*480, 16.7M Colors,TN screen,
● No touch / Resistive touch panel Optional,
● TTL and CMOS Interface,10Pin_1.0mm FPC
● Download by SD card or on-line serial port
● Development Platform : TA / DGUSⅡ ( DGUSⅡ pre-installed )
● Normal viewing, 70°/70°/50°/70°（L/R/U/D）
● Software DWIN DGUS V7.6GUI Development, no code can be designed by UI designer;
● With GUI&OS dual-core, GUIs with many controls ,DWIN OS kernel is open to the user for the second-development, through DWIN OS language or KELI C52.
-
12.1″HMI display Module DMG80600C121_03W(Commecial grade)
Features:
● Based on self-designed T5L1 ASIC, 16.7M Color, 24bit.
● 800*600 Pixel TFT LCD.
● Has onboard speakers and the Power should be <2W
● TA(Instruction set)/ DGUSⅡdevelopment system
● No touch screen/Resistive touch screen/Capacitive touch screen Optional;
● TTL and 232 Interface available, user use 8 Pin2.0mm FCC connection wire connect Products
● The finished project will be downloaded by SD card or uart port
● Using DWIN DGUS V7.6 GUl Development tool , no coding skills required. Easy to develop
● IPS wide view Angle:85/85/85/85 (URUD);
● Reserved WIFI and USB module interface
● Wi-Fi module: connect to the cloud platform to update remotely
● USB module: download files by USB flash disk
● With GUI &OS dual-core GUI with functional controls. DWIN OS kemel is open to the user for the second-development, vie DWIN OS language or KEIL C51
-
15″ HMI LCD display Model: DMG10768C150_03W(Commercial grade)
Features:
● Based on our self-designed T5L ASIC,16.7M Color, 24 bit, 1024*768 Pixel ,IPS TFT LCD Touch;
● No touch screen/Resistive touch/Capacitive touch panel
● TTL interface with 8Pin_2.0mm connection wire
● SD card Download or on-line serial port
● Easy use DWIN DGUS V7.6 GUIs Development, no skillful required;
● Dual Development System: DGUS II/TA (Instruction Set);
● View Angle: 85/85/85/85（L/R/U/D）
● With GUI & OS dual-core, GUI with many controls. DWIN OS kernel is opened to the user for the second-development, by DWIN OS Language or C51
-
12.1″TFT LCD Display DMG12800C121_02WTC(Commercial grade)
Features:
● Based on self-designed T5L ASIC,16.7M Color, 24 bit, 1280*800 Pixel TFT TN LCD;
● Capacitive touch panel;
● TTL interface with 8Pin_2.0mm connection wire;
● Download SD card or on-line serial port;
● PC software: DWIN DGUS V7.6 GUIs Development, no code skills required;
● Dual Development System: DGUS II/TA (Instruction Set);
● View Angle: 70/70/50/70（L/R/U/D）;
● With GUI & OS dual-core, GUI with different controls. DWIN OS kernel is open to the user for the second-development, via DWIN OS Language or C51;
-
3.5 Inch T5L Function Evaluation Board Model:EKT035A
Features:
● Self-designed T5L 8051 display control chip, 262K Color, 18bit, 320*240 Pixel;
● Capacitive touch screen(Glass+Glass structure, sensitivity could be adjusted for the use of extra front tempered glass or acrylic panel);
● TTL Interface, 50Pin-0.5mm FCC connection wire;
● Multiple user interfaces(I/Os, CAN, PWM, AD, UARTs) for debugging;
● SD card or DGUS TOOL on-line serial port downloading ways;
● DWIN DGUS V7.6 GUIs development, easy to use, 0 code quick developing;
● Dual development system: DGUS II(GUI tool with built-in UI modules) / TA(Hex commends instruction set), switched by download the kernel via SD card;
● IPS View Angle: 85/85/85/85 (L/R/U/D), free viewing angle;
● GUI & OS dual-core, GUI with rich built-in touch and display controls in DGUS tool. DWIN OS kernel is open to the user for the second-development, via DWIN OS programming language or KEIL C51 language.
-
4.0 inch HMI LCD Display DMG48480C040_03W(Commercial grade)
Features:
● 4.0-inch, 480*480 pixels resolution, 16.7M colors,IPS TFT LCD;
●LCM interface: FPC50_0.5mm,RGB interface;
● No touch/Resistive touch /Capacitive touch ;
● Download via SD card or on-line serial port,480×480 pixels;
● Easy-to-use DWIN DGUS V7.6 GUIs Development, no coding skills required;
● ITO film + ITO glass/G+G structure with surface cover of Asahi tempered glass;
● IPS View Angle: 85°/85°/85°/85° (L/R/U/D);
● DWIN OS kernel is open to the user for the second-development, via DWIN OS language or KEIL C51.
