7.0 Inch Highlight TFT LCD Display DMG80480T070_09W(Industial grade)
Features:
● 7.0 Inch,800*RGB*480,262K Colors, TN Display,High brightness ;
● Anti-UV, with conformal coating,Without/Resistive /Capacitive touch screen;
● TTL/RS232 User interface; 8Pin_2.0mm cable;
● Download via SD card or on-line uart serial port,or optional USB and Wifi ;
● Developed by DWIN DGUS V7.6 GUIs Development,no code required;
● DGUSⅡ/TA(Instruction set) two development mode available;
● View Angle: 70/70/50/70(L/R/U/D);
● Fast running dual core,GUI &OS core of 8051 processor.
-
7.0″LCD Touch Screen Model:DMG10600T070_01W(Industrial grade)
Features:
● Based on T5L ASIC 7.0 Inch,1024xRGBx600,16.7M Colors, IPS Touch Module;
● No touch screen/Resistive touch screen/Capacitive touch screen Optional;
● TTL interface with 8Pin_2.0mm connection wire;
● Download via SD card or on-line serial port;
● Software DWIN DGUS V7.6 GUIs Development.do not need skillful technology;
● Development System: DGUSⅡ/TA(Instruction set);
● IPS View Angle:85/85/85/85(L/R/U/D);
● With GUI&OS dual-core, GUI with different controls, DWIN OS kernel open to the second-development, via DWIN OS language or KELI C51;
-
7.0 Inch LCD Display DMG10600T070_09W(Industrial grade)
Features:
● Based on T5L2 ASIC 7.0 Inch,1024xRGBx600,16.7M Colors, IPS screen;
● High brightness No Touch/Capacitive touch/Resistive touch : 700nit/650nit/600nit
● TTL interface; 8Pin_2.0mm FCC connection cable;
● The finished project will be downloaded by SD card or uart port;
● Easy-to-use DWIN DGUS V7.6 GUIs Development tool.No coding skills required;
● Dual Development System:DGUSⅡ/TA(Instruction set);
● IPS View Angle:85/85/85/85(L/R/U/D);
● With GUI&OS dual-core, GUI with functional controls, DWIN OS kernel is open to the user for the second-development, via DWIN OS language or KELI C51.
-
7 Inch Machine UART Monitor DMG12800C070_03W(Commercial grade)
Features:
●Based on T5L2, running DGUS II system, commercial grade;7.0-inch, 800*1280 Pixels resolution, 16.7M Colors, IPS-TFT-LCD, wide viewing angle;
●No /Resistive /Capacitive touch screen Optional;
●UART2: ON=TTL/CMOS; OFF=RS232 UART4: ON=TTL/CMOS; OFF=RS232;8Pin_2.0mm socket for power supply and serial communication;
●Two Download ways:via SD card or on-line serial port;
●Easy-to-use DWIN DGUS V7.6 GUIs Development.no coding skills required;
●Dual Development System:DGUSⅡ/TA(Instruction set);
●With IPS View Angle:85/85/85/85(L/R/U/D);
●With GUI & OS dual-core, GUI with rich controls. DWIN OS kernel is open to the user for the second-development, via DWIN OS language or KEIL C51. -
7.0 Inch Outdoor Severe Environment Screen DMG10600S070_03W（Harsh Environment）
Features:
● Based on T5L2, running DGUS II system, for outdoor severe environment application.
● 7.0-inch, 1024*600 pixels resolution, 16.7M colors, IPS-TFT-LCD, wide viewing angle.
● With UV protection and AG function.
● Capable of working under ultra-wide temperature range from -40~85℃ with conformal coating.
● Support RS232 and RS485 communication.
-
7.0 Inch UART Screen DMG80480S070_03W(Harsh Environment)
Features:
● Based on T5L1, running DGUS II system.
● 7.0-inch, 800*480 pixels resolution, 16.7M colors, IPS-TFT-LCD, wide viewing angle.
● Capable of working under ultra-wide temperature range from -40~85℃ with conformal coating
● Support RS232 and RS485 communication
● Download via SD card or on-line serial port;
● Easy-to-use DWIN DGUS V7.6 GUIs Development.no coding skills required;
-
7.0 Inch With Shell HMI Display DMG80480C070_15WTR(commercial grade)
Features:
● 800*480 resolution, 262K colors, TN-TFT-LCD;
● Resistive touch screen;
● RS232 and RS485 Interface, 8Pin3.81mm Socket connection wire;
● Download via SD card or on-line serial port;
● 8MBytes NOR Flash, for fonts, pictures and audio files;
● Brightness is up to 200nit;
● TN View Angle: 70/70/50/70 (L/R/U/D) ;
-
7 Inch RS232/RS485 Touch Screen DMG80480T070_A5W(Industrial Grade)
Features:
● Self-designed T5L ASIC, 16.7M Color, 24bit, 800*480 Pixel;
● All in one resistive touch screen,built-in speaker, photosensitive resistance;
● RS232/RS485 Interface,8Pin_3.81mm Socket ;
● Download via SD card or on-line serial port ;
● DWIN DGUS V7.6 GUIs Development tool ;
● Two Development Modes: DGUS II/ TA(Commend);
● TN View Angle:70/70/50/70 (L/R/U/B);
● Support connect with PLC,Modbus protocal is supported.
-
7.0 Inch Medical UART Touch Display DMG80480K070_03W(Medical Grade)
Features:
●Based on self-designed T5L1 ASIC, 16.7M Color, 24bit
● No touch screen/Resistive touch screen/Capacitive touch screen are avaliable
● 8Pin_2.0mm(RS232),2Pin_2.0mm(RS485)
● Download via SD card or on-line serial port
● Easy-to-use DWIN DGUS V7.6 GUIs Development, no coding skills required
● TN, TFT LCD View Angle: 70°/70°/50°/70° (L/R/U/D)
-
7.0 Inch CAN LCD Touch Display DMG10600T070_A5W(Industrial Grade)
Features:
● Based on T5L2, running DGUS II system, industrial grade.
● 7.0-inch, 1024*600 pixels resolution, 16.7M Colors, IPS-TFT-LCD, wide viewing angle.
● RS232/RS485 Interface,8Pin_3.81mm Socket*1，(WTC has CAN bus interface *1;)
● Touch Option: Resistive/Capacitive;
● 16/32MBytes NOR Flash, expandable to 64Mbytes NOR Flash;
● Onboard speaker. Power: 2W;
● Protective Level:IP65(front);
-
7 Inch HMI LCD Display Touch Panel Model:DMG80480C070_04W(Commercial grade)
Features:
● Based on T5L0, running DGUS II system, commercial grade.;
● 7.0-inch, 800*480 pixels resolution, 262K colors, TV-TN-TFT-LCD.
● No touch screen/Resistive touch screen/Capacitive touch screen Optional;
● TTL/RS232 interface; 10Pin_1.0mm connection wire;
● Download via SD card or on-line serial port;
● Easy-to-use DWIN DGUS V7.6 GUIs Development, no coding skills required;
● Dual Development System:DGUS Ⅱ/TA(Instruction set);
● TV viewing angle, 70°/70°/40°/30°（L/R/U/D）;
● With GUI&OS dual-core, GUI with rich controls, DWIN OS kernel is open to the user for the second-development via DWIN OS language or KELI C51.
-
7 Inch LCD Display Touch Screen DMG80480C070_03W(Commercial grade)
Features:
● Based on T5L1, running DGUS II system, commercial grade;
● 7.0-inch, 800*480 pixels resolution, 16.7M colors, TN-TFT-LCD.
● No touch screen/Resistive touch screen/Capacitive touch screen Optional;
● TTL/RS232 interface; 10Pin_1.0mm FCC connection wire;
● Download via SD card or on-line serial port;
● Easy-to-use DWIN DGUS V7.6 GUIs Development.no coding skills required;
● Dual Development System:DGUS Ⅱ/TA(Instruction set);
● Normal viewing angle, 70°/70°/50°/70°（L/R/U/D）;
● With GUI&OS dual-core,GUI with rich controls,DWIN OS kernel is open to the user for the second-development,via DWIN OS language or KELI C51.
