Specification
| Main Chip | T5F0 |
| User Interface | 30Pin_0.5mm FPC |
| FLASH | 8MB NOR Flash |
| UI Version | DGUS II / TA |
| Dimensions | 4 inch |
| Resolution | 480*480 |
| Viewing Area (VA) | 71.9mm (W)×70.2mm (H) |
| Viewing Angle | Wide viewing angle (85°/85°/85°/85° typical), high contrast, and good color reproduction. |
| Backlight Service Life | >20000 hours |
| Brightness | 50nit |
| Brightness Control | 100-level brightness adjustment (Flickering may occur at 1%-30% of max brightness; not recommended for use in this range) |
| Note: Use dynamic screen saver to prevent afterimages from prolonged fixed page display. | |
| Type | CTP (Capacitive Touch Panel). |
| Structure | G+G structure with tempered glass surface and hardness ≥ 6H. |
| Light Transmittance | >20% |
| Rated Power | <2W | |
| Operating Voltage | 4.5~5.5V, typical value of 5V. | |
| Operating Current | 300mA | VCC=5V, max backlight. |
| 130mA | VCC=5V, backlight off. | |
| Recommended power supply: 5V 0.5A DC. | ||
| Operating Temperature | -10℃~60℃ |
| Storage Temperature | -20℃~70℃ |
| Operating Humidity | 10%~90%RH, typical value of 60% RH. |
