Specification
| LCD Type | IPS, TFT LCD. |
| Viewing Angle | Wide viewing angle (85°/85°/85°/85° typical), high contrast, and good color reproduction. |
| Resolution | 1920×1080 Pixel |
| Active Area (AA) | 477.24mm(W)×268.71mm (H) |
| Viewing Area (VA) | 477.24mm(W)×268.71mm (H) |
| Backlight Service Life | >50000H |
| Brightness | 800nit |
| Note: Use dynamic screen saver to prevent afterimages from prolonged fixed page display. | |
|
Type |
Capacitive touch panel |
|
Structure |
G+G structure, 4mm tempered glass cover plate, Anti-Glare effect |
| IK(cover) | IK08 |
| Power Voltage | 18~36V, typical value 24V. |
| Current Parameters | 1540mA@24V |
| Recommended power supply: 24V 2A DC. | |
| Item |
Conditions |
Min |
Typ |
Max |
Unit |
| Operation Temperature |
60%RH at 5V voltage |
-20 |
25 |
70 |
℃ |
| Storage Temperature |
- |
-30 |
25 |
80 |
℃ |
| Operation Humidity |
25℃ |
10% |
60% |
90% |
RH |
| ESD |
Contact: ±6KV; Air: ±8KV |
||||
| EFT |
±2KV; Class B |
||||
| CS |
0.15-80M 10Vrms Class A |
||||
| RE |
CLASS A |
||||
| CE |
CLASS A |
||||
| Anti-UV |
Y |
||||
| Anti-Glare |
Y |
||||
| Protective Level |
IP65(Front) |
||||
| Power Interface | 3PIN_Φ2.0DH |
| Display Interface | HDMI-A(23PIN_HDMI_SH) |
| Touch Interface | USB-A/Type-C optional |
| Speaker Interface | 2Pin_2.0mm |
