| LCD Type | IPS, TFT LCD |
| Viewing Angle | Wide viewing angle (85°/85°/85°/85° typical), high contrast, and good color reproduction. |
| Resolution | 1024×600 Pixel |
| Active Area (AA) | 222.70mm (W)×125.30mm (H) |
| View Area (VA) | 222.70mm (W)×125.30mm (H) |
| Backlight Service Life | >20000H |
| Brightness | 450nit |
| Note: Use dynamic screen saver to prevent afterimages from prolonged fixed page display. | |
| Touch Panel | Capacitive touch panel |
| Material | Tempered cover glass |
| Hardness | 6H |
| Power Voltage | 9-36V, typical value 12V. | |
| Current Parameters | 460mA | VCC=12V (Standard supply voltage) |
| Recommended power supply: 12V 1A DC. | ||
| Item |
Conditions |
Min |
Typ |
Max |
Unit |
| Operation Temperature |
60%RH at 12V voltage |
-20 |
25 |
70 |
℃ |
| Storage Temperature |
- |
-30 |
25 |
80 |
℃ |
| Operation Humidity |
25℃ |
10% |
60% |
90% |
RH |
| ESD |
Air:±8KV ; Contact:±6KV |
||||
| Protective Level |
IP65 (Front) |
||||
| Power Interface | 3PIN_DC_DVΦ2.1 |
| Display Interface | HDMI port (23PIN_HDMI_SH) |
| Touch Interface | USB 2.0 |
