10.1 Inch IPS 200nit 1024*600 Multi-touch Capacitive touch HD Interface LCD Display Monitor HDW101_001LZ01
Features:
● 10.1 Inch, 1024*600, 16.7M Colors, Multi-touch support, Capacitive touch screen
● IPS screen, wide viewing angle 85/85/85/85 (L/R/U/D)
● With USB port & HD interface on board
● LED backlight, with 200 nit brightness
● High standard TFT LCD module HMI display with touch panel
● Suitable for Windows, Raspberry Pi, Linux, Android system
● Transiting high resolution video and multi-channel audio data in digital form while maintaining high-quality
Specification
|
Item |
Parameter |
Description |
| Color |
16.7M(16777216)colors |
24 bit color 8R8G8B |
| Panel Type |
IPS |
IPS TFT LCM ,wide viewing angle |
| Viewing Angle |
85/85/85/85(L/R/U/D) |
Best View: symmetrical |
| Active Area (A.A.) |
222.70(W)*125.30(H) |
1024*600 |
| Resolution |
1024*600 |
- |
| Backlight |
LED |
≥20000H(Continuous working with maximum brightness, time of the brightness decays to 50%) |
| Brightness |
200nit |
- |
| Note: Displaying of high-contrast still images for more than 30 minutes may result in residual images. Please add animation to avoid this problem. | ||
|
Item |
Conditions |
Min |
Typ |
Max |
Unit |
| Power Voltage |
- |
6 |
12 |
36 |
V |
| Operating Current |
VCC=12V |
- |
330 |
- |
mA |
|
Item |
Conditions |
Min |
Typ |
Max |
Unit |
| Working Temperature |
60%RH at 12V voltage |
-20 |
25 |
70 |
℃ |
| Storage Temperature |
- |
-30 |
25 |
80 |
℃ |
| Working Humidity |
25℃ |
10% |
60% |
90% |
RH |
| ESD |
Air discharge: ± 8KV |
||||
|
Item |
Conditions |
Min |
Typ |
Max |
Unit |
| Socket | 6-36V power interface, HD interface | ||||
| USB Interface | Yes | ||||
| SD Card Slot | None | ||||
| Peripheral | Capacitive touch panel |
