Specification
| LCD Type | IPS, TFT LCD. |
| Viewing Angle | Wide viewing angle (85°/85°/85°/85° typical), high contrast, and good color reproduction. |
| Resolution | 1280×800 Pixel |
| Active Area (AA) | 216.96mm(W)×135.60mm (H) |
| Viewing Area (VA) | 218.00mm(W)×136.60mm (H) |
| Backlight Service Life | >50000H |
| Brightness | 1100nit |
| Note: Use dynamic screen saver to prevent afterimages from prolonged fixed page display. | |
| Touch Panel | OCA bonded capacitive touch panel |
| Material | Tempered cover glass |
| IK(cover) | IK08 |
| Power Voltage | 3.6-6V, typical value 5V. |
| Current Parameters | 1800mA@5V |
| Recommended power supply: 5V 2A DC. | |
| Item |
Conditions |
Min |
Typ |
Max |
Unit |
| Operation Temperature |
60%RH at 5V voltage |
-30 |
25 |
80 |
℃ |
| Storage Temperature |
- |
-30 |
25 |
80 |
℃ |
| Operation Humidity |
70℃ |
10% |
60% |
90% |
RH |
| ESD |
Contact: ±8KV; Air: ±15KV |
||||
| RE |
CLASS B |
||||
| Anti-UV |
Y |
||||
| Anti-Glare |
Y |
||||
| Interface | LVDS, See dimension drawing for interface definition (VDD=+5.0V) |
| Socket |
DVI_I interface |
