10.1 Inch 1280x800 IPS 300nit HD LCD Display Module Capacitive Touch Panel for Raspberry pi HDW101_004L

Features:

● 10.1 inch IPS screen, Multi-touch support, Capacitive touch screen

● ≥30000H(Continuous working with maximum brightness, time of the brightness decays to 50%)

● 6-36V power interface

● Suitable for Windows, Linux and Android system,Such as Raspberry Pi.

● With USB port & HD interface on board

● Transiting high resolution video and multi-channel audio data in digital form while maintaining high-quality

Send email to us Datasheet 3D Data

Specification

Display

Color	16.7M colors，24-bit 8R8G8B
Panel Type	IPS-TFT-LCM, wide viewing angle
Viewing Angle	85°/85°/85°/85°(L/R/U/D)
Display Area（A.A）	216.96mm(W)x135.60mm(H)
Resolution	1280*800
Backlight	LED. ≥30000H(Continuous working with maximum brightness, time of the brightness decays to 50%)
Brightness	300nit

Voltage

Power Voltage

6~36V, typic value: 12V

Reliability Test

Interface

Socket	Power interface, HD interface
SD slot	None
USB	YES

Peripheral

HDW101_004L

Capacitive touch panel

Packing Capacity & Dimension

Dimension	229.70(W)x149.30(H)x18.60(T)mm
Net Weight	425g
